INTREPID™ M – CAL IV Certified T&C Gas-tight connection
INTREPID™ M is a proprietary premium connection certified in accordance with ISO 13679 for CAL IV requirement level.
This connection guarantees safe operation under severe pressure and temperature. It can withstand up to 100% tensile, compression, internal and external pressure loads.
This connection allows an angle of deviation up to 40º / 100ft
SIZE RANGE:
|
Product |
In |
|
Casing |
4 1/2” – 13 3/8” |
|
Tubing |
2 3/8” – 4 1/2” |
STEEL GRADES:
|
API |
|
Sour Service |
|
High Collapse |
INTREPID™ M applications and features: WELL APPLICATIONS:
- Intermediate casing
- Production casing
- Tie-back
- Liner
- Tubing
- Vertical
- Directional
- Horizontal
- Threaded & Coupled (T&C)
- “Hook” thread profile
- “Metal-to-metal” gas tight system
- True ID
- Dope pocket
- Available with BEST DRY solution
- High Collapse
- High Torque
- Special Clearance
- Special Bevel
